KEEL MAX,Heavy load capacity
CARGO DRONE
KEEL MAX
Product Description
Specification
KEELMAX product parameter table
Product Model : KEELMax
Symmetrical wheelbase : 2416mm
Material : carbon fiber composite material, aviation aluminum
Product size : 3000*3000*600mm(arm expansion, tripod expansion, blade removal)
2100*550*550 mm(folding box)
Weight
Empty weight = 40kg(excluding batteries) Empty weight = 100kg(including four batteries)
Maximum load: ≤100kg
Maximum takeoff weight: ≤200kg
Effective flight time
No load, ≤ 70 minutes . 30kg load, ≤ 65 minutes . 50kg load,<50 minutes . 100kg load ≤ 30 minutes
Hover accuracy vertical : ±0.2m, horizontal ±0.1m(without RTK)
Maximum rotation Angle: 100°/s
Maximum pitch Angle : 25°
Maximum ascent speed : 5m/s
Maximum descending speed : 3m/s
Maximum horizontal speed : 18m/s
The maximum flight altitude : 5500m
The maximum wind speed : 18m/s
IP protection level : IP55
Working environment temperature: -20℃-+55℃
Battery : 18S-72Ah*4 sets
Battery weight (single) : about 15.5kg
Battery size: 436*230*92mm
Want to Choose the Right Propeller for You?
Take a quick test to find the right propeller for you.
If You have any Questions, Please Contact Us
If You have any Questions, Please Contact Us
Warning
1. Please be careful when using the propellers as the spinning propellers may cause serious injury.
2. The structural strength of the propellers are fully tested. Please make sure the propellers are not used beyond thelimits. Please do not tempt to test the strength of the propellers by bending them by hands. Any damage or loss from improper use will be on the users’account.
3. Please make sure all the accessories are mounted properly.
4. Please check on the propellers before flight and make sure they are in good condition. Please replace propellers with new ones if fault is found with them.
5. For storage, please keep them away from hostile environments including but not limited to that of H2O, SO2, NO2, Cl2, organosilicon, cyanogroup and phenol. Ambient temperature is recommended between 0 and 40℃ at less than 80% humidity.
6. Please apply anaerobic screw locking glue of medium or above strength when install propellers onto motors.
7. Please use the propellers in compliance with local laws and regulations.
8.Please do not use it for military purposes, otherwise any risk and responsibility caused will be borne by the customer.
